DESIGN/APPLICATION DATA:
Simple fountain nozzle comprised of a set of 4mm water jets arranged in such a way that on rising they look like the diamonds and falling like the stars. The angel given to the jets means that, from wherever they are positioned,spectators can see the front & back jet cross over producing an aesthetics effect of great beauty in the architectural fountain. The range is comprised of three sizes with 15, 20 & 30 fountain jets
SPECIFICATION DATA:
Construction shall be cast bronze with precision clear stream brassnozzle neoprene gasket and stainless steel fasteners.
LIGHTING SPECIFICATION:
Model | Voltage | Wattage | Colour |
PF 1140 | Na | Na | Na |
PF 1142 | 12V DC | 12W | RGB/WARM WHITE |
PF 1144 | 12V DC | 18W | RGB/WARM WHITE |
OPERATING DATA:
Noise | Moderate |
Visibility | Excellent |
Splash/Mist | Moderate |
Aeration Quality | Poor |
ELECTRICAL CABLE
RGB lighting: - H0?RN-F- 4 core 0.75 sq/mm Warm White lighting: H0?RN-F- 2 core 1 sq/mm
